THE MANUFACTURING OF ORGAN BLOWERS AND OTHER HIGH-PRESSURE CENTRIFUGAL FANS





TECHNICAL DATA OF ORGAN BLOWERS OF TYPE LVM4

1400 rotations/minute 50 Hz
Pressure range: 120 mm water column
TYPE
For organ stops up to app.
Wind production
m3/min
Pressure range
mm WS
Motorpower
kW
Net weight app.
3-ph.A.C.
1-ph.A.C.
LVM4-008-120/400
LVM4-008-120/230
17-20
8
 120
0,4
91
LVM4-014-120/400
LVM4-014-120/230
 28-32
 14
 120 0,57
 98
LVM4-021-120/400
LVM4-021-120/230
 40-45
 21
 120 0,75
 114
LVM4-028-120/400
-
 50-55
 28
 120 1,2
 123
LVM4-035-120/400
 -
 60-65
 35
 120 1,5
 128
LVM4-043-120/400
 -
 68-72
 43
 120 1,9
 166
LVM4-052-120/400
 -
 78-85
 52
 120 2,25
 168
LVM4-062-120/400
 -
 89-100
 62
 120 2,7
 169
